← Back to transducers and generatorsPush-Pull Ultrasonic Transducers
High-efficiency push-pull transducers for consistent ultrasonic energy in demanding precision-cleaning systems.
Custom sizes are available. Standard tank, chamber, basket, fixture and material-handling configurations can be tailored to the application.
Ultrasonic power engineered for new tanks, retrofits and demanding precision-cleaning processes.
High-efficiency push-pull transducers for consistent ultrasonic energy in demanding precision-cleaning systems. The equipment can be configured around part geometry, soils, chemistry, load size, throughput and the required downstream condition.
Efficient energy transfer
The push-pull design converts generator output into powerful ultrasonic activity with high operating efficiency.
Multiple standard lengths
A broad standard length range helps match transducer coverage to the working tank and part envelope.
Material options
Stainless-steel and titanium configurations support different chemistry, temperature and durability requirements.
From tank geometry to uniform cavitation
The transducer, generator, mounting and frequency are selected together so the ultrasonic field supports the part, soil and cleanliness target.
Define the cleaning load
Review tank dimensions, part geometry, soil, chemistry, temperature and cleanliness requirements.
Select frequency and power
Match frequency, watt density and generator capacity to the cleaning objective and component sensitivity.
Engineer placement
Position and mount the transducers to distribute energy effectively through the working volume.
Validate performance
Confirm cavitation, coverage, process time and repeatability under representative production conditions.
Equipment images
Standard configuration
Standard equipment provides a proven starting point for application development; final specifications should be confirmed for the selected process.
| Specification | Configuration |
|---|---|
| Operating efficiency | Greater than 97% |
| Standard frequencies | 25, 30 or 40 kHz |
| Construction options | Stainless steel or titanium |
| Standard length range | 19 lengths from 13.31″ to 67.91″ |
Custom sizes are available. eChem and Crest can evaluate tank or chamber dimensions, baskets, material handling, ultrasonics and supporting equipment for your application.
Application benefits
High power density
Efficient conversion supports demanding industrial soil removal.
Predictable coverage
Standardized lengths make system layout and tank integration more straightforward.
Frequency selection
Choose 25, 30 or 40 kHz to balance cleaning intensity and part sensitivity.
Application durability
Construction material can be selected for the process chemistry and operating environment.
Generator integration
Transducers are paired with a compatible generator and control package.
Custom system fit
Quantity, positioning, length and power are engineered around the tank and throughput.
Build the right cleaning process
eChem can evaluate your parts, soils, throughput, chemistry, utilities and cleanliness requirements before a Crest system is specified.
